50kg strain gauge Half-bridge Load Cell weight Sensor

The 50kg Half-bridge Experiments Body Scale Load Cell Sensor measures the correct force is applied to the outer side of the strain E-shaped beam portion of the sensor (i.e., a strain gauge affixed to the intermediate, adhesive coating with white beam arms); and the outer edges to form a shear force in the opposite direction, i.e., middle strain beam bending necessary changes can occur under stress, strain beam side by another force should not be a barrier.

FEATURES & SPECIFICATIONS

• Capacity : 50(Kg).
• Output Sensitivity : 1.0±0.1(mv/v)
• Nonlinearity : 0.03(%FS).
• Repeatability : 0.03(%FS).
• Input Resistance : 1000(Ω).
• Insulation Resistance : ≥5000(MΩ).
