The ESP32 WROOM is a potent, all-purpose WiFi-BT-BLE MCU module that is intended for use in a wide range of jobs, from low-power sensor networks to the most difficult ones, such voice encoding, music streaming, and MP3 decoding. This module’s ESP32S chip, which is made to be scalable and adaptive, is at its heart. The clock frequency of the two CPU cores, which ranges from 80 MHz to 240 MHz, can be changed independently. The user has the option of turning off the CPU and using the low-power coprocessor to continuously check the peripherals for adjustments or the crossing of thresholds. Capacitive touch sensors, Hall sensors, and other peripherals are all integrated within the ESP32. Ethernet, high-speed SDIO/SPI, UART, low-noise sensing amplifiers, SD card interface, and I2C are other examples.This module supports output at 22 dBm and data rates up to 150 Mbps. Users can connect to their phones or emit low energy beacons for their detection via Bluetooth. Wi-Fi allows for a wide physical range and a direct connection to the internet through a Wi-Fi router. The ESP32 chip requires less than 5 A, making it ideal for battery- or wearable-electronic applications.
TECHNICAL SPECIFICATION
- Microcontroller: ESP32 WROOM-32
- Interface: USB Type-C
- Serial Chip: CP2102
- Connectivity: WiFi and Bluetooth
- Pin Count: 38 pins
- Processor: Dual-core processor
- Development: Suitable for IoT and embedded systems development
- Applications: Versatile applications including home automation, IoT devices, and robotics
- Compact Design: Small form factor for easy integration
- Power Supply: Can be powered via USB or external power source
- Compatibility: Compatible with various development environments and programming languages
